Modero X Series® G5 Touch Panels

MXD/T-701 7" Modero X Series® G5 Touch Panels

MXT-701

The MXT-701 7" Modero X Series® G5 Tabletop Touch Panel (FG5968-53) (FIG. 1) is ideal for boardrooms,

conference rooms, or auditoriums where a panoramic control surface is needed to provide access to multiple functions

simultaneously while remaining elegantly unobtrusive. In residences, it is perfect for kitchens, home theaters, or home

offices where the panoramic control surface can be used to manage systems throughout the house.

The MXT-701 features a 7.3" x 4.8" (186 mm x 122 mm), 8.8" (222 mm) diagonal display, with a viewable area of 6.05"

x 3.54" (154 mm x 90 mm), 7.0" (178 mm) diagonal.

The device communicates via Ethernet (10/100 port, RJ-45 connector, supported IP and IP-based protocols: UDP, TCP,

ICMP, ICSP, IGMP, DHCP, SSH, DNS, RFB for VNC, and HTTP) and USB (2 USB host 2.0, Type A ports).

The MXT-701 also supports Near Field Communication (NFC) technology (please see the NFC on page 9 for more

information).

FIG. 1 MXT-701 touch panel

FIG. 2 MXT-701 side view

Sleep/Settings Button

5.0"

(126 mm)

NFC Sensor

7 5/16"

(187 m)

4 1/8" (105 mm)

USB Ports (2)

Sleep/Settings Button

(74 mm)
