• 0101, the output is set to a PN23 sequence, based on ITU
0.150 using the equation x
23
+ x
18
+ 1. The seed value is
0x003AFF. (See the device data sheet for applicable
deviations.)
• 0110, the output is set to a PN9, based on ITU 0.150 using
the equation x
9
+ x
5
+ 1. The seed value is 0x000092. (See
the device data sheet for applicable deviations.)
• 0111, the output words toggle between all 1s and 0s.
• 1000, the output is set to the user mode, controlled by Bit 7
and Bit 6. If the output is in user mode 0x08 and Bit 7 and
Bit 6 are set to 00, the pattern stored in the user pattern
memory is statically placed on the output. If set to 01, the
output toggles between User Pattern 1, stored in 0x019 and
0x01A, and User Pattern 2, stored in 0x01B and 0x01C. If
set to 10, User Pattern 1 is placed on the output for one
conversion cycle; then the output is set to all 0s. If set to 11,
User Pattern 1 and User Pattern 2, on the next encode
cycle, are placed on the output. Further conversion cycles
result in all 0s as determined by the output data format.
• 1001, the output is placed in a 1/0 bit toggle mode for serial
output testing. This forces an alternating 1/0 transition on
the serial output stream.
• 1010, the first half of the bits are set to 0 and the last half of
the bits are set to 1. The cycle repeats for the next word
frame (see Table 8 for details).
• 1011, the first bit of the serial word is set high and the
following bits in the word are set low.
• 1100, the serial words shown in Table 8 are shifted.
Bit Mode 1101 and Bit Mode 1110 are reserved for future use.
Bit Mode 1111 is reserved for chip-specific test requirements.
Table 8. Output Test Modes, Register 0x00D
Output
Test
1
2
2
Subject to
Data Format
0000 Off Not applicable Not applicable Yes
0001 Midscale short 1000000000000000 Not applicable Yes Offset binary code shown
0100 Checkerboard 1010101010101010 0101010101010101 No
0101 PN sequence long Not applicable Not applicable Yes PN23
3
ITU 0.150
x
23
+ x
18
+ 1
3
ITU 0.150
x
9
+ x
5
+ 1
0111 1/0 word toggle 1111111111111111 0000000000000000 No
Register 19 to Register 1A
Register 1B to Register 1C
Useful in serial output mode
1010 1× sync 0000000011111111 Not applicable No Lower resolution truncates both
a leading and a trailing digit
1011 1 bit high 1000000000000000 Not applicable No Useful in serial output mode
1100 Mixed-frequency 101000110011 (12 bit)
1001100011 (10 bit)
10100001100111 (14 bit)
10100011 (8 bit)
Not applicable No Useful in serial output mode
1101 Reserved Not applicable Not applicable Not applicable Not applicable
1
All devices may not support all modes. See the device data sheet for details.
2
Truncated from the right for lower resolutions.
3
See the device data sheet for applicable deviations.
