BLOWER ASSEMBLY:
ELECTRICAL ASSEMBLY:
No. No.Description Description
1
2
3
4
5
Screw (ST3*10)
Electrical cover
Capacitor
PCB
Electrical box base
No. No.Description Description
1
2
3
4
Grid
Blower
Impeller
Motor
6 Screw (ST3*6)
