necessary, some workpiece should be directly earthed, but directly grounding is not
allowed in some countries, user can achieve this effect only by selecting the
appropriate capacitor according to the regulations of the host countries.
 Shielding
The shielding of surrounding equipment and other cables can reduce the
electromagnetic interference. The whole welding area can be shielded for special
applications.
Main technical information
1、 Main technical parameter
Model
MIG-270E
Function
MIG
TIG
MMA
Power Supply
Voltage(V)
220V±15%
Frequency(Hz)
50/60
Rated Input Power(KW)
5
3.7
6
Rated Input Current(A)
23
17
27
Effective Current(A)
14.5
10.8
17
Welding Current
Range(A)
20-160
No-Load Voltage(V)
55V
Duty cycle
（
%
40℃ 10min）
40%
160A,22V
160A,16.4V
160A,26.4V
100%
101A,19V
101A,14V
101A,24V
Power Factor
0.93
Protection Class
IP21S
Insulation Class
F
Cooling
AIR
Net Weight(KG)
About7.5
Dimension(MM)
406*171*245
