16 Operation Guide Grain bagger GB-series Anderson Group
Shaft diameter and splines 1 3/8 Z6
Drive shaft
Main shaft Single cardan joint / single cardan joint with shear bolt
Safety devices
Drive shaft Shear bolt (M10 x 60 mm class 8.8)
Crushing rollers
6 groves/in model Corn
9 groves/in model Other cereal
Length (23 1/2in) 595mm
Diameter (8 1/2in) 215 mm
Rotation speed Mobile roller: 770RPM
Fixed roller: 990RPM
Takeoff Hex belt profile BB (8)
Compression screw
Length 2133 mm (84 in)
Diameter 405 mm (16 in)
Hardness 56 HRC
Rotation speed 540RPM
Takeoff Cardan shaft
Hopper
Size of the upper opening 60in (1524 mm) x 96 in (2438 mm)
Height 40in (1016 mm)
Volume 1.4 m
3
(40bushels)
Rotation 360
0
Bag
Diameter
5ft (1.52 m) or 6.5ft (2 m)
Loading auger
Diameter 9in (200mm)
Length 12ft (3.6 m)
Takeoff Hydraulic motor
Speed Up tp 450 rpm at 10 gpm 2000 psi
Capacity 50 tons/h (2000 bushels/h) at 450rpm
