Anderson Group Round Bale Wrapper IFX720 – Operator's Guide 30
Figure 34 — Pusher Rails
Do not grease the two square tubes
that are used as guide rails for the
pusher; they have been greased at
the factory. Greasing them could
attract dust and prevent the pusher
from sliding.
Instead, lubricate these tubes with
new oil where indicated by a label,
as well as the part of the tubes
located in the rear when the pusher
is forward.
6.3 Greasing points
After every 200 bales, you should grease your wrapper
with a grease gun in the following places:
NOTE: We recommend you use synthetic
grease.
Figure 35 — Greasing Point
Figure 36 — Two FrontAxles
Figure 37 — Two Rear Axles
Figure 38 — Stretcher Gears
