Anderson Group Round Bale Wrapper IFX720 – Operator's Guide 7
1 Introduction
Congratulations! You have just purchased an Anderson
wrapper. Your wrapper is a quality piece of machinery for
wrapping round bales in a tube.
1.1 Overview
The following illustration shows the main components of
the IFX Wrapper.
1 Hoop
2 Safety guard
3 Plastic film roll
4 Guide roller
5 Tailgate
6 Spear
7 Hoop brake pedal
8 Control panel
9 Work light
10 Trigger
11 Push rod
Figure 1 – Main Components of the Wrapper
The following table shows and describes the labels on the
wrapper, excluding the ones on the control panel. These
labels are shown in Table 2
Table 1 — Labels on the Wrapper
Label Description
Deactivating the
pusher
Deactivate the plastic
watch
Install the plastic film
Right bale guide
Left bale guide
Lubrication point (oil)
Grease point (grease)
