* The above illustration shows an example of installation.
The exact installation confi guration may be slightly different.
[WHiC56, LWHiC56]
Indoor Wall Mounted, Power Vent/Sealed Model
Front Cover
Intake Pipe
Exhoust Pipe
Gas Supply Valve
Drain Pipe
Discharges the
condensate.
Water Drain Valve
(with Water Filter)
Water Supply Valve
(Inside Water Inlet) ( p.39)
External Weatherproof Power Point
Main Unit
Burner on indicator
If there is a problem with the unit,
a lamp will fl ash on the front of
the unit. (
p.44)
To Next Page
