* The above illustration shows an example of installation.
The exact installation confi guration may be slightly different.
[WHi49, LWHi49]
Indoor Wall Mounted, Power Vent/Sealed Model
Main Unit
Front Cover
Water Supply Valve
Gas Supply Valve
Coaxial Pipe
Water Drain Valve
(with Water Filter)
(Inside Water Inlet) ( p.39)
External Weatherproof Power Point
General Parts-2
Burner on indicator
If there is a problem with the unit,
a lamp will fl ash on the front of
the unit. (
p.44)
