Modular Power Meter
Modular power meter version 1.0 Page 14 / 40
5.11.
Software Upgrade
Easy program upgrade can be done in one of next ways:
- writing the upgrade file with a USB-RS485-RJ45 cable to the Volt1000 meter (this
uses a PC program ModbusLink, see chapter 7);
- writing the upgrade with our proprietary protocol over MODBUS;
In a chain, the Volt1000 or first current meter can forward its upgrade to the attached
Cube1000AN/RoCo2000AN/Spark5A meters. This has to be initiated via the display.
5.12.
Ordering Codes
Code Description
Volt1000 3-ph+N voltage sensor with MODBUS + master
RoCo2000AN 4x2000A Rogowsky coil current sensor
Cube1000AN 4x1000A current cube sensor
Spark5A 3x5A current sensor with measurement of partial discharge
ModbusCable5M 5m MODBUS RTU cable with RJ45 plug + striped end
ModbusLink PC program to upgrade, configure and read out the sensors
USB-RS485 USB to modbus cable to be used with the MobusLink program
Table 5-1 Ordering Codes
