PF 0x3500-0x35FF
Ithd 0x3600-0x36FF
S 0x3700-0x37FF
Minimum value float16 U, Uthd, F 0x4000-0x40FF
I 0x4100-0x41FF
P 0x4200-0x42FF
Q 0x4300-0x43FF
Cosphi 0x4400-0x44FF
PF 0x4500-0x45FF
Ithd 0x4600-0x46FF
S 0x4700-0x47FF
Table 6-2 Modbus master table overview
Name Register
Address
Description Units Format
U1N 0x0000 Phase voltage L1 Vrms float32
U2N 0x0002 Phase voltage L2 Vrms float32
U3N 0x0004 Phase voltage L3 Vrms float32
UN 0x0006 Neuter voltage (PE is reference) Vrms float32
U12 0x0008 Line voltage L1-L2 Vrms float32
U23 0x000A Line voltage L2-L3 Vrms float32
U31 0x000C Line voltage L3-L1 Vrms float32
U1THD 0x000E Total harmonic distortion – U1 % float32
U2THD 0x0010 Total harmonic distortion – U2 % float32
U3THD 0x0012 Total harmonic distortion – U3 % float32
Frequency 0x0014 Frequency Hz float32
I1.1 0x0100 Current sensor 1 channel 1 Arms float32
I1.2 0x0102 Current sensor 1 channel 2 Arms float32
I1.3 0x0104 Current sensor 1 channel 3 Arms float32
I1.4 0x0106 Current sensor 1 channel 4 Arms float32
I2.1 0x0108 Current sensor 2 channel 1 Arms float32
I2.2 0x010A Current sensor 2 channel 2 Arms float32
I2.3 0x010C Current sensor 2 channel 3 Arms float32
I2.4 0x010E Current sensor 2 channel 4 Arms float32
...
I15.1 0x0170 Current sensor 15 channel 1 Arms float32
I15.2 0x0172 Current sensor 15 channel 2 Arms float32
I15.3 0x0174 Current sensor 15 channel 3 Arms float32
I15.4 0x0176 Current sensor 15 channel 4 Arms float32
P1.1 0x0200 Real power sensor 1 channel 1 W float32
P1.2 0x0202 Real power sensor 1 channel 2 W float32
P1.3 0x0204 Real power sensor 1 channel 3 W float32
P1.4 0x0206 Real power sensor 1 channel 4 W float32
P2.1 0x0208 Real power sensor 2 channel 1 W float32
P2.2 0x020A Real power sensor 2 channel 2 W float32
P2.3 0x020C Real power sensor 2 channel 3 W float32
P2.4 0x020E Real power sensor 2 channel 4 W float32
...
P15.1 0x0270 Real power sensor 15 channel 1 W float32
P15.2 0x0272 Real power sensor 15 channel 2 W float32
P15.3 0x0274 Real power sensor 15 channel 3 W float32
