Anerma Electronics Volt1000 - Table 6-13 Modbus Energy Counter Registers - Float32

Modular Power Meter
Modular power meter version 1.0 Page 33 / 40
Einjected-s1 0x7400 Injected real energy for sensor 1 KWh float32
Einjected-s2 0x7402 Injected real energy for sensor 1 KWh float32
...
Einjected-s15 0x741C Injected real energy for sensor 15 KWh float32
Etotal-s1 0x7500 Total real energy for sensor 1 KWh float32
Etotal-s2 0x7502 Total real energy for sensor 1 KWh float32
...
Etotal-s15 0x751C Total real energy for sensor 15 KWh float32
Eqpos-ch1 0x7600 Positive reactive energy for
sensor 1 channel 1
Kvarh float32
Eqpos-ch2 0x7602 Positive reactive energy for
sensor 1 channel 2
Kvarh float32
...
Eqpos-ch60 0x7676 Positive reactive energy for
sensor 15 channel 4
Kvarh float32
Eqneg-ch1 0x7700 Negative reactive energy for
sensor 1 channel 1
Kvarh float32
Eqneg-ch2 0x7702 Negative reactive energy for
sensor 1 channel 2
Kvarh float32
...
Eqneg-ch60 0x7776 Negative reactive energy for
sensor 15 channel 4
Kvarh float32
Eqtot-ch1 0x7800 Total reactive energy for
sensor 1 channel 1
Kvarh float32
Eqtot-ch2 0x7802 Total reactive energy for
sensor 1 channel 2
Kvarh float32
...
Eqtot-ch60 0x7876 Total reactive energy for
sensor 15 channel 4
Kvarh float32
Eqpos-s1 0x7900 Positive reactive energy for sensor 1 Kvarh float32
Eqpos-s2 0x7902 Positive reactive energy for sensor 2 Kvarh float32
...
Eqpos-s15 0x791C Positive reactive energy for sensor 15 Kvarh float32
Eqneg-s1 0x7A00 Negative reactive energy for sensor 1 Kvarh float32
Eqneg-s2 0x7A02 Negative reactive energy for sensor 2 Kvarh float32
...
Eqneg-s15 0x7A1C Negative reactive energy for sensor 15 Kvarh float32
Eqtot-s1 0x7B00 Total reactive energy for sensor 1 Kvarh float32
Eqtot-s2 0x7B02 Total reactive energy for sensor 2 Kvarh float32
...
Eqtot-s15 0x7B1C Total reactive energy for sensor 15 Kvarh float32
Table 6-13 Modbus energy counter registers – float32
Example:
As an example, input 1 of sensor 1 has the following counters:
Name Value
[Joule]
64-bit int (hex) Value [kWh] 32-bit float (hex)
Econsumed 120 GJ $0000 001B F08E B000 33333.333 kWh $4702 3556
Einjected 30 GJ $0000 0006 FC23 AC00 8333.333 kWh $4602 3556
Etotal 90 GJ $0000 0014 F46B 0400 25000 kWh $46C3 5000
