Anerma Electronics Volt1000 - Individual Table - Info; Table 6-8 Modbus Individual Table Registers - Measurements

Modular Power Meter
Modular power meter version 1.0 Page 29 / 40
U3thd 0x5012 Total harmonic distortion – U3 % float32
Frequency 0x5014 Frequency Hz float32
Rotation
field
0x5016 - -
float32
I1 0x5018 Current channel 1 Arms float32
I2 0x501A Current channel 2 Arms float32
I3 0x501C Current channel 3 Arms float32
I4 0x501E Current channel 4 Arms float32
P1 0x5020 Real Power channel 1 W float32
P2 0x5022 Real Power channel 2 W float32
P3 0x5024 Real Power channel 3 W float32
P4 0x5026 Real Power channel 4 W float32
Q1 0x5028 Reactive Power channel 1 var float32
Q2 0x502A Reactive Power channel 2 var float32
Q3 0x502C Reactive Power channel 3 var float32
Q4 0x502E Reactive Power channel 4 var float32
CosPhi1 0x5030 Cos(φ) channel 1 - float32
CosPhi2 0x5032 Cos(φ) channel 2 - float32
CosPhi3 0x5034 Cos(φ) channel 3 - float32
CosPhi4 0x5036 Cos(φ) channel 4 - float32
PF1 0x5038 Power factor channel 1 - float32
PF2 0x503A Power factor channel 2 - float32
PF3 0x503C Power factor channel 3 - float32
PF4 0x503E Power factor channel 4 - float32
I1thd 0x5040 Total harmonic distortion – I1 % float32
I2thd 0x5042 Total harmonic distortion – I2 % float32
I3thd 0x5044 Total harmonic distortion – I3 % float32
I4thd 0x5046 Total harmonic distortion – I4 % float32
S1 0x5048 Apparent power channel 1 VA float32
S2 0x504A Apparent power channel 2 VA float32
S3 0x504C Apparent power channel 3 VA float32
S4 0x504E Apparent power channel 4 VA float32
Table 6-8 Modbus individual table registers – Measurements
6.3.5. Individual table – Info
Name Register
Address
Description Units Format
SerialNbr 0x5100 Device serial number - int32
ProdDate 0x5102 Production date - date
Type 0x5104 Type:
- 201.0.0.1 = voltage sensor
- 201.0.0.2 = current sensor
- int32
Subtype 0x5106 Subtype for I sensor:
- 1.1.25.4 = 25cm Rogowsky coils
- 9.0.0.4 = current cube
- int32
Software 0x5108 Software version number - int32
Hardware 0x510A Hardware version number - int32
Status 0x510C Sensor status (for test purposes only) - int32
Master flag 0x510E <>0 for the first sensor on the bus
=0 for other sensors on the bus
- int32
