Modular Power Meter
Modular power meter version 1.0 Page 36 / 40
This example contains the packet with the following parameters:
- the meter serial number is 2029004 (0x001EF5CC)
- baudrate 38400 (communication setting=0x03)
- address 13 (0x0D)
The resulting packet is (the 3 parameters are underlined):
00 17 FE FF 00 01 FF 03 00 09 12 B5 7E 3A 1D C8 F9 00 03 00 13 00 00
00 1E F5 CC 00 0D F5 DE
Alternatively, this works also with the target address 13 (OD):
0D 17 FE FF 00 01 FF 03 00 09 12 B5 7E 3A 1D C8 F9 00 03 00 13 00 00
00 1E F5 CC 00 0D 35 D6
