Installation of Brass Nut Fixing Plate
21
Name QTY Note
Z Axis
Nut Fixing Plate
1
M5*14 Scrwe 2
M5 T Nut 2
M3*18 Screw 4
M3 Nut 4
Keep the both side aluminium profile at the same level during installation
M3 Screw
Hole
