Name QTY Note Name QTY Note
Z Axis Limited Switch
Fixing Plate
1 M5*12
Screw
2
Z Axis Limited Switch 1 M5 T Nut 2
M2 Self-tapping
Screw
2
Install the Limited Switch Fixing Plate in the location above
Installation of Z Axis Limited Switch
27
