Installation of X Limited Switch
22
Name QTY Note
X Limited Switch
Fixing Plate
1
X Limited Switch 1
M2*12
Self-tapping Screw
2
M5*12 Scrwe 2
M5 T Nut 2
Keep the limited switch fixing plate align
at X motor fixing plate
