Product Specifications
Document No. 992012. Issue 16 – 12.01.21
Page 5
Key to Fig. 1
QA3 Patient Trolley
(and build options)
QA3 Emergency Trolley
(and build options)
Castor Diameter
Ø150mm
(5.9”)
Ø200mm
(7.9”)
Ø150mm
(5.9”)
Ø200mm
(7.9”)
NOTE: Ø150mm are the standard option, Ø200mm is a build option.
Height Range:
A.
Minimum Trolley Height
475mm
(18.7”)
520mm
(20.5”)
535mm
(21.1”)
580mm
(22.8”)
Maximum Trolley Height
775mm
(30.5”)
820mm
(32.3”)
835mm
(32.9”)
880mm
(34.6”)
NOTE: Height is measured from the floor to the patient platform and does not include the
mattress.
Ground Clearances Under the Trolley Base:
B.
Under the 5
th
Wheel Pedal
Mechanism, Head End
90mm
(3.5”)
90mm
(3.5”)
90mm
(3.5”)
90mm
(3.5”)
C.
Under the Base Frame, Foot End
90mm
(3.5”)
135mm
(5.3”)
90mm
(3.5”)
135mm
(5.3”)
D.
Under the Lifting Column
44mm
(1.7”)
90mm
(3.5”)
44mm
(1.7”)
90mm
(3.5”)
NOTE: The ground clearance figures quoted are general guidelines; as per Fig.1 the trolley
is compatible with hoists with leg heights up to 120mm on either castor option, Ø150 or
Ø200mm.
Mattress Dimensions (standard) and <800> Mattress (build option):
E.
Std. Mattress Length
2025mm (79.7”)
<800> Mattress Length
F.
Std. Mattress Width
700mm (27.6”)
<800> Mattress Width
800mm (31.5”)
G.
Std. Mattress Depth
90mm (3.5”)
<800> Mattress Depth
105mm (4.1”)
NOTE: Refer to Section 37, ‘K8 Pressure Care Mattress’, for full specification details.
Trolley Length:
H.
Patient Platform Flat
2150mm (84.6”)
I.
Backrest Raised
1820mm (71.7”)
J.
Backrest & KneeFlex Raised
1700mm (66.9”)
Trolley Widths (standard) and <800> (build option) :
K.
Side Rails Up (std.)
805mm (31.7”)
Side Rails Up (<800>)
905mm (35.6”)
L.
Side Rails Down (std.)
735mm (28.9”)
Side Rails Down (<800>)
795mm (31.3”)
Brakes Off
735mm (28.9”)
M.
Width between Side Rails Up
(std.)
745mm (29.3”)
Width between Side Rails Up
(<800>)
845mm (33.3”)
Backrest & KneeFlex Articulations:
N.
Manual Function Backrest
0 - 90°
Powered Function Backrest
0 - 70°
O.
KneeFlex
0 - 30°
N/A
IV Pole:
P.
Maximum Height of Pole
2110mm (83.1”)
2155mm (84.8”)
Maximum Weight per Hook
3kg (6.6lbs) or 3 Litres (101.4 fl oz.)
Safe Working Load
6kg (13lb)
Trendelenburg:
Trendelenburg
12°
Reverse Trendelenburg
10°
NOTE: Trendelenburg is a standard trolley function, Reverse Trendelenburg is an optional
function.
