Selection button (5.4); The selection button is used to reduce the amount of
coffee set in the display. When the lowest value is reached the display returns
to the maximum amount.
Start/stop button (5.5); The start/stop button is used to start and
(emergency) stop the coffee making process.
2. TECHNICAL DETAILS
Model M200 M202 MT200 MT202v
Article number 10551 10562 10572 10587
Buffer stock coffee 3.6 l./ 28 cups 7.2 l. / 56 cups - -
Hourly coffee capacity 18 l./144 cups 36 l./288 cups 18 l./144 cups 18 l./144 cups
Jug filling time approx. 6 min. approx. 8 min. approx. 7,5 min./2.2 l. approx. 7,5 min./2.2 l.
coffee amount 1 -3 l. 1 -3 l 1 -3 l. 1 -3 l.
Supply voltage 220-240V~ 220-240V~ 220-240V~ 220-240V~
Frequency 50-60Cy 50-60Cy 50-60Cy 50-60Cy
Total output 2250W 3500W 2100W 2100W
Filter paper 90/250 90/250 90/250 90/250
Min. water pressure 0.2 MPa (2 bar) 0.2 MPa (2 bar) 0.2 MPa (2 bar) 0.2 MPa (2 bar)
Max. water pressure 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar)
Dimensions See fig. 1 See fig. 2 See fig. 3 See fig. 4
Empty weight 7,5 kg. 13,6 kg. 7 kg. 9 kg.
Transport dim. (lxwxh) 600x275x530 mm 600x490x540 mm 440x270x670 mm 440x270x670 mm
Transport weight 9,6 kg. 17,9 kg. 9 kg. 11 kg.
All technical details are subject to change
3. INSTALLATION
3.1 Unpacking
The machine has been carefully packed to prevent damage being caused to your new
coffee maker. Remove the packing carefully without using sharp objects. Check if the
appliance is complete. The appliance is delivered with the following accessories:
M200 M202 MT200 MT200v
Glass jug 2 4 - -
Basket filter 1 2 1 1
Filter paper (25 pcs.) 1 1 1 1
Coffee measuring cup 1 1 1 1
Funnel 1 1 1 1
Water connection hose 1 1 1 1
Coffee fur remover 1 1 1 1
Scale remover 1 1 1 1
Manual 1 1 1 1
Please contact your dealer if any parts are missing or damaged.
