AnkerMake M5 - At a Glance; Assembling the Printer

0403
At a Glance
USB-C Port
Touch Screen
Camera
Extruder
Nozzle
Power Socket
Indicator Light
PTFE Feeding Tube
Extruder Clip
Gantry Frame
Platform
PEI Plate
Power Switch
Ventilation Holes
Assembling the Printer
Step 1.
Installing Gantry Frame
What You Need
M5
Open the box, then place the
foam cover (A)
on a at, stable surface.
Take out all the accessories in the
foam (B)
, then place the
foam (B)
next to the
foam cover (A)
as support.
Platform Screws ToolboxGantry Frame
