EN 14
Dimensions 45.5×45.3×23.6 mm / 1.8×1.8×0.9"
Battery capacity 350mAh
Charging time 1.5 hours
Operating time 6 hours (15 hours with the charging case)
On-board recording 4GB / 7 hours
Analog input 3.5 mm TRS (for a lavalier microphone)
Transmission range 200 m / 656 ft (line of sight)
Signal-to-noise ratio ≥ 70dB A-Weighted
Equivalent noise 22dB A-Weighted (typical)
Sensitivity -36dBV/Pa at 1KHz (gain = 0dB)
Maximum sound pressure
level
120dB SPL
Polar pattern Omnidirectional
Frequency range 50Hz - 20kHz
Item Receiver
Input 5V
0.72A
Weight 37g / 1.3 oz
Dimensions 43.2×35×30.4 mm / 1.7×1.4×1.2"
Battery capacity 350mAh
Charging time 1.5 hours
Operating time 6 hours (15 hours with the charging case)
Analog output 3.5 mm TRS (for headphones or a camera)
