SCPI Device Message Details
2.2 Level
The table below shows device messages for level.
Table 2.2-1 Device messages for level
Function Device Message
Reference Level
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel <real>
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel?
RF Attenuator
[:SENSe]:POWer[:RF]:ATTenuation <rel_ampl>
[:SENSe]:POWer[:RF]:ATTenuation?
RF Attenuator
Auto/Manual
[:SENSe]:POWer[:RF]:ATTenuation:AUTO ON|OFF|1|0
[:SENSe]:POWer[:RF]:ATTenuation:AUTO?
Log Scale Range
:DISPlay:WINDow[1]:TRACe:Y[:SCALe][:LOGarithmic]:PDIVision
<rel_ampl>
:DISPlay:WINDow[1]:TRACe:Y[:SCALe][:LOGarithmic]:PDIVision?
Scale Mode
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:SPACing LINear|LOGarithmic
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:SPACing?
Log Scale Unit
:UNIT:POWer DBM|DBMV|V|W|DBUV|DBUVE|DBUVM
:UNIT:POWer?
Linear Scale Range
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:LINear:PDIVision <percent>
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:LINear:PDIVision?
Log Scale Line
:DISPlay:WINDow[1]:TRACe:Y[:SCALe][:LOGarithmic] <lines>
:DISPlay:WINDow[1]:TRACe:Y[:SCALe][:LOGarithmic]?
Ref.Level Offset
Value
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEvel:OFFSet <rel_ampl>
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEvel:OFFSet?
Reference Level
Offset Mode
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel:OFFSet:STATe ON|OFF|1|0
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel:OFFSet:STATe?
Pre Amp
[:SENSe]:POWer[:RF]:GAIN[:STATe] ON|OFF|1|0
[:SENSe]:POWer[:RF]:GAIN[:STATe]?
Log Scale Line
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:LINE[:LOGarithmic] <lines>
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:LINE[:LOGarithmic]?
Impedance
[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude] 50|75
[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude]?
