Chapter 4 OTDR Commands
4-12
4.3.11 SOURce:PULSe Command
Syntax: SOURce:PULSe<wsp><value>
Parameters: <value>
Numeric format
Range: Integer PW value returned by querying available pulse width command.
Available pulse width values are dependant on current range/resolution settings.
Description: Set current pulse width.
Example: sour:puls 100
Response: None
Errors: (–200, "std_execGen, Test is Active")
(–224, "std_illegalParmValue, Invalid Parameter Value")
4.3.12 SOURce:PULSe? Command
Syntax: SOURce:PULSe?
Parameters: None
Description: Query current pulse width.
Example: sour:puls? --- 100<END>
Response: value is current pulse width in nanoseconds (NS)
Errors: None
4.3.13 SOURce:PULSe:ENHanced:AVAilable? Command
Syntax: SOURce:PULSe:ENHanced:AVAilable?
Parameters: None
Description: Queries if the enhance mode is available for currently set pulse width.
Example: sour:puls:enh:ava? --- 1<END>
Response: Boolean value 1 or 0.
Errors: None
