ANSIMAG K+1516 - 14- Shipping Weights

56
14. APPROXIMATE SHIPPING WEIGHTS of PUMP & MOTOR
MOUNTING
14-a. ANSI Pumps with NEMA Motor Mounting [lbs(kg)]
K1516 K326, K326s,
K3156
K436 K1518 K3158
NEMA T/TC frame
size (Drive)
close coupled close coupled close coupled close coupled close coupled
143 - 145 (A) 90 (41) 118 (54) 128 (58) 93 (42) 119 (54)
182 - 184 (A) 87 (39) 115 (52) 124 (56) 90 (41) 116 (53)
182 - 184 (B) 86 (39) 115 (52) 124 (56) 89 (40) 116 (53)
213 - 215 (A) 90 (41) 121 (55) 131 (59) 93 (42) 123 (56)
213 - 215 (B) 90 (41) 122 (55) 132 (60) 94 (43) 123 (56)
213 - 215 (C) 91 (41) 123 (56) 132 (60) 94 (43) 123 (56)
254 - 256 (B) 97 (44) 133 (60) 143 (65) 100 (45) 134 (61)
254 - 256 (C) 97 (44) 134 (61) 144 (65) 101 (46) 135 (61)
284 TSC (C) 130 (59) 140 (64) 150 (68) 134 (61) 141 (64)
Long coupled 117 (53) 141 (64) 152 (69) 134 (61) 154 (70)
14-b. ANSI Pumps with IEC Motor Mounting [lb(kg)]
K1516 K326 K436 K1518 K3158
IEC
frame size
close
coupled
close
coupled
close
coupled
close
coupled
close
coupled
80 122(55) 156(71) 167(76) 139(63) 168(76)
90 121(55) 155(70) 166(75) 138(63) 167(76)
100/112 120(54) 153(69) 164(74) 136(62) 166(75)
132 150(68) 163(74) 174(79) 167(76) 175(79)
160 180(82) 193(88) 204(93) 196(89) 206(94)
14-c. ISO Pumps with IEC Motor Mounting [lb(kg)]
Ki32160 Ki50160 Ki65160 Ki32200 Ki40200
IEC
frame size
close
coupled
close
coupled
close
coupled
close
coupled
close
coupled
80 134(61) 136(62) 159(72) 149(68) 161(73)
90 132(60) 133(60) 158(72) 149(68) 160(73)
100/112 130(59) 132(60) 157(71) 147(67) 159(72)
132 186(84) 187(85) 166(75) 157(71) 169(77)
160 216(98) 271(123) 183(83) 219(99) 230(104)
14-d. Motor weight
Refer to motor manufacturer's catalog for motor weights.
