ANSIMAG K+1516 - Page 8

8
PUMP CODE K+ 1516 C 02 AK 1 1 1 1 1 A
SERIES
K+ Series K+
HYDRAULICS
NEMA ISO JIS
1516 i32160 j40160
1518 i32200 j40200
3156 -- --
3158 i40200 j50200
326 i50160 j50160
326S -- --
436 i65160 j65160
CONFIGURATION
Close Couple C
Long Couple L
Wet End W
Cartridge NC
MOTOR FRAME
NEMA IEC, JIS
Wet End Only 00 80 IEC & JIS 30
56C 01 90 IEC & JIS 31
143/145TC 02 100/112 IEC & JIS 32
182/184TC 03 132 IEC & JIS 33
213/215 TC 04 160 IEC & JIS 34
254/256 TC 05
284/286 TSC 07
324/326 TSC 09
DRIVE SIZE
AK – 10 hp AK
BK – 15 hp BK
CK – 30hp CK
O-RING
Viton 1
EPDM 2
GORTEX 4
WEAR PARTS
SIC / CFR-PTFE 1
SIC / SIC 2
Carbon / CFR - PTFE 3
Carbon / SIC 4
WETTED MATERIAL
CFR -ETFE 1
GFR – PFA 2
ETFE w/ PFA Impeller 4
PUMP CASE MATERIAL
CI / ETFE 1
CI / GFR-PFA 3
316 SS 4
Hastelloy® B 5
Hastelloy® C 6
PUMP CASE FLANGE
150 1
300 2
ISO PN 16 3
JIS 10 4
THIRD PARTY CERTIFICATION
None 0
ATEX / CE A
Notes: A. Gortex® PTFE encapsulated Viton with a Gortex® wrap.
B. Wear Parts Material is shaft material/bushing material.
C. Pump Case Material is base material/lining. Hastelloy and 316SS is unlined.
