55
PART LIST 6
BEARING FRAME ONLY
Group 1 Group 2
Item
#
Part Name
Qty
K1516, K326s,
K3156, K1518
K3158,
K326, K436
Bearing Frame Assembly P2349 P2350
01 Hex Bolt, 3/8-16X7/8 4 HH3/8X0.88
04 SKF Ball Bearing #6207NRJ 1 K3502
05 SKF Ball Bearing #6207 1 K3501
06 Inpro Bearing Isolator 1518-A-09944-0 2 P2434
08 O-Ring #153 1 K3603
10 Wave Spring Washer 1 K3702
11 3/8” NPT Plug 3 K3902
12 1” NPT Sight Window 1 K4002
14 Bearing Frame Shaft 1 P2565 P2010
15 ¼” X 1/8” Reducing Bushing 1 K3802
16 1/8” Breathing Tube 1 K3801
17 Bearing Frame Housing 1 P1846 P2015
18 Key, ¼ X ¼ X 1-1/4 1 P1632E
19 Key, 3/16 X 3/16 X 1-1/2 1 P1632A
20 Bearing Frame Cap 1 P2564
21 Bearing Frame Oil 1 P2501
26 Hex Bolt, ½-13 X 3.00, Fully Threaded 2 HH1/2X3.00FT
27 Eyebolt 1 N/A K4701
To Next Page
