air outlet opening, making sure that the
product adapter hook is in front of the
seat of the hook on the outlet opening,
and fasten the outlet hose with the
adapter by pushing them in the direction
of the arrow.
2. The adapter hook should be in front of the
hook seat on the air outlet.
3. Check that the product adapter engages
properly with the bottom slot on the air
outlet opening.
FIG. 6
Preparation of adjustable window insert
1. Adjust the window insert to the size of the
window.
2. If the window is so long that it needs two
window inserts, use the screw to join the
window inserts when they are adjusted to a
suitable length.
3. If the window is so long that it needs three
window inserts, use two screws to join the
window inserts when they are adjusted to a
suitable length.
FIG. 7
INSTALLATION
NOTE:
Choose one of the three installation methods
below for the outlet hose and the adjustable
window insert.
Vertical sliding window
1. Cut the self-adhesive foam rubber seals A
and B to a suitable length and fasten them
on the jamb and window frame as shown
in the diagram.
FIG. 8
2. Place the window insert in the window
opening.
FIG. 9
3. Cut the non self-adhesive foam rubber seal
C to a suitable length for the width of the
window. Place the seal between the glass
and the jamb to prevent air and insects
coming into the room.
FIG. 10
4. If necessary t the safety fastener with the
2 screws as shown in the diagram.
FIG. 11
5. Place the window insert adapter in the
hole in the window insert.
FIG. 12
Horizontal sliding window
1. Cut the self-adhesive foam rubber seals A
and B to a suitable length and fasten them
on the jamb and window frame as shown
in the diagram.
FIG. 13
2. Place the window insert in the window
opening.
FIG. 14
3. Cut the non self-adhesive foam rubber seal
C to a suitable length for the height of the
window. Place the seal between the glass
and the jamb to prevent air and insects
coming into the room.
FIG. 15
4. If necessary t the safety fastener with the
2 screws.
5. Place the window insert adapter in the
hole in the window insert.
FIG. 16
Wall mounting
1. Make a hole with a diameter of 125 mm in
the wall for the wall outlet adapter B.
2. Fasten the wall outlet adapter B to the wall
with the 4 supplied screws and plugs.
3. Connect the outlet hose (with wall outlet
adapter A) to wall outlet adapter B.
FIG. 17
