LINE OUTPUT AND ZONE 2 OUTPUT
Line output is a 2-channel version of the selected input with xed output level. This can be
used with a headphone amp which has its own volume control.
Zone 2 has its own volume control and can be used two ways:
- For independent source selection, connect the source using analog input, or optical/
coaxial input as long as the source is 2-channel PCM. This connection can be used
in conjunction with HDMI connection for the main zone.
- For similar operation as Line Output but with volume control, set Follow Main to
Always in the setup menu (setup is explained later).
OPTICAL AND COAXIAL DIGITAL AUDIO
If HDMI audio from a Dolby Digital, DTS, or 2-channel PCM source is problematic or
takes too long to switch, use of coax/optical audio connection is recommended (HDMI
video can still be used). Older cable and satellite receivers often benet from this.
The optical output provides a passthrough of coax/ optical input.
