Description of the parts.
a Headrest.
b Backrest.
c Fixed armrest.
d Removable armrest (optional).
e Stop foot board.
Dental chair of ANTHOS A2.5 and ANTHOS A2.7 model
Dental chair of ANTHOS A1.3 L model
Operating time.
The operating and rest times are as follows:
work 25 sec. - rest 10 min.
Maximum permitted load.
• Maximum permitted load on all other dental chairs: 190 kg.
• Maximum permitted load on headrest: 30 kg.
• Maximum load supported by armrest: 68 kg.
Do not exceed these values.
CRUSHING HAZARD
• Despite the presence of safety systems to prevent crushing, there is always a minimum residual risk due to moving parts.
The positions already stored ensure a safety distance between dental chair and floor.
Do not store lower dental chair positions, and in any case pay attention to the risk of crushing.
• Pay attention to the patient and the staff during dental chair descent.
Dental units of A5 and A6 PLUS model
