Anviz C2 User Manual

74
Select the check box and then modify the parameters. Click the button [OK] to
save
5.1.4.3 Terminal Information
Display terminal information as follows:
Click the button [Retrieve] to retrieve the terminal information. Click the button
[Cancel] to close the window.
5.1.4.4 Open the door via software
Open the door via software
If you click the item [Open the door via software], you can see the information in
the main interface as follows:
And meanwhile you can hear the sound from the relay.
5.1.4.5 Message Management
Send the message to the user when he clock in.
Click the item, a window pops up as follows:
[2011-08-25 13:35:58]1[Head office]Open the door via software successfully!
[2011-08-25 10:10:36]1[1]Set the network parameters successfully；

Anviz C2 Specifications

General

Identification Mode	Fingerprint, Password
Communication	TCP/IP, USB
Operating Temperature	0°C~45°C
Power	DC 12V
Operating Humidity	20%
