AOC AGON PRO AG276QZD User Manual

Make sure the ventilation holes are not blocked by tables or curtains.
Please do not knock or drop the monitor while it is being operated or transported.
Please refer to the "Screen Maintenance" instructions.
Based on the characteristics of OLED products, it is recommended to use this product continuously for no more than 4 hours. This product uses a variety of technologies to eliminate possible image retention, with
Please do not use the monitor under vibrating vortex or high impact conditions during operation.
If the product emits a strange smell, strange sound or smoke, immediately disconnect the power plug and contact a service center.
5
other
Machine Translated by Google

AOC AGON PRO AG276QZD Specifications

General

Panel type	-
Color gamut	98.5 %
Pixel pitch	0.2292 x 0.2292 mm
Screen shape	Flat
Response time	0.03 ms
Backlight type	W-LED
Display diagonal	26.5 \
Surface hardness	2H
Anti-glare screen	Yes
Display technology	OLED
Native aspect ratio	16:9
Maximum refresh rate	240 Hz
Viewable size, vertical	330 mm
sRGB coverage (typical)	100 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	1500000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	67.3 cm
Viewable size, horizontal	586.75 mm
Display brightness (typical)	1000 cd/m²
DisplayPort version	1.4
Headphone connectivity	3.5 mm
RMS rated power	5 W
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Tilt angle range	-5 - 23 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Certification	ISO 9241-307
Product color	Black
Market positioning	Gaming
Exterior finish type	Textured
Package depth	189 mm
Package width	731 mm
Package height	477 mm
Package weight	10330 g
USB cable length	1.8 m

Weight and Dimensions

Depth (with stand)	233.9 mm
Width (with stand)	604.4 mm
Height (with stand)	526.6 mm
Weight (with stand)	6410 g
Depth (without stand)	71.3 mm
Weight (without stand)	4910 g
