AOC AGON PRO AG276QZD - Mounting and Base Installation

Mounting Brackets and Bases
1
3
2
M4x10mm
100mm
100mm
M4-P0.7
L=10+0
- 0.5
Dk=8.0±0.2 H=2.0±0.1
M=4.0Max
Wall hanging iron parts:
Install:
Wall hanging iron screw specification: M4*10mm Base screw specification: M6*13mm (effective thread 5.5mm)
Please follow the steps below to set up or remove the base.
7
tear down:
2
3
1
4
D3.86-3.92
