AOC CU34P3CV User Manual

27
Specification
General Specification
Panel
Model Name CU34P3CV
Driving System TFT Color LCD
Viewable Image Size 86.4 cm Diagonal(34’’ Wide Screen)
Pixel Pitch
0.23175mm(H) x 0.23175mm(V)
Others
Horizontal Scan Range 30k-160kHz
Horizontal scan Size(Maximum) 797.22 mm
Vertical Scan Range 48-100Hz
Vertical Scan Size(Maximum) 333.72mm
Optimal Preset Resolution
3440x1440@60Hz
Max resolution 3440x1440@100Hz(HDMI,DisplayPort,USB C)
Plug & Play VESA DDC2B/CI
Power Source
100-240V~, 50/60Hz, 2A
Power Consumption
Typical(Default Brightness And Contrast) 35W
Max. (Brightness = 100, Contrast =100) ≤180W
Standby Mode
≤
0.5W
USB C
USB C Double-sided Connectable Plug
Ultra-highSpeed Data And Video Transmission
DisplayPort Built-in DisplayPort Alt Mode
Power Supply USB PD Version 3.0
Maximum Power Supply
Up to 65W (5V/3A,7V/3A,9V/3A,10V/3A, 12V/3A,15V/3A,
20V/3.25A)
Physical
Characteristics
Input Connector
HDMI/DisplayPort/USB C/Earphone/RJ45 Input/USB
Upstream/USB3.2 Gen1x4(Includes 1 Fast Charger)
RJ45 Ethernet LAN (10M/100M/1000M)
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°C~ 40°C
Non-Operating -25°C~ 55°C
Humidity
Operating 10% ~ 85% (Non-Condensing)
Non-Operating 5% ~ 93% (Non-Condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC CU34P3CV Specifications

General

Brand	AOC
Model	CU34P3CV
Category	Monitor
Language	English
