PC Input Signal Reference Chart
After connecting the PC to the TV, set the output signal from the PC according to the chart below.
Presetting PC Mode
Standard Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
VESA 640 x 480 31.469 59.94
VESA 800 x 600 37.879 60.317
VESA 1024 x 768 48.363 60.004
VESA 1280 x 720 44.772 59.855
VESA 1280 x 768 47.396 59.995
VESA 1280 x 1024 63.981 60.02
VESA 1440 x 900 55.469 59.901
VESA 1680 x 1050 65.29 59.954
VESA 1920 x 1080 67.5 60
Video Input Signal Reference Chart
After connecting the video input to the TV, set the output signal from the video input according to the chart below.
Presetting Video Mode
Standard Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
SD 480i 15.734 60
SD 480P 31.5 60
HD 720P 45 60
HD 1080i 33.75 60
FHD 1080p 67.5 60
Standard Definition Interface
You can also enjoy traditional program by using a DVD player or VCR Player. Connect this equipment to your TV via the Composite Input or
S-Video Input on the back of your TV.
Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV.
