AOC LE23H062 User Manual

English
2.2 Connecting External Devices
Connect external devices such as VCRs, Set-Top-Box, DVD players, video game
consoles, earphones, or a PC to the TV using the appropriate ports on the rear of the
TV.
2.2.1 Connecting External Earphones
Note:
• External speakers or headphones are not included with the TV.
• The internal TV speakers will not output sound when headphones are
plugged in.
• Use external speakers with built-in amplifiers only.
• Only one external device for sound can be connected at a time.
Speakers
Headphones
(Built-in Amplifiers)
9
English

AOC LE23H062 Specifications

General

Package depth	445 mm
Package width	616 mm
Package height	118 mm
Package weight	6800 g
Child lock	No
Plug and Play	Yes
Image formats supported	JPG
Display diagonal	23 \
Display brightness	300 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	1080p
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Viewing angle, horizontal	170 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	FCC, cULus, RoHS, EPA4.0
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	60 Hz
Power consumption (typical)	45 W
RMS rated power	10 W

Weight and Dimensions

Depth (with stand)	190 mm
Width (with stand)	561 mm
Height (with stand)	389 mm
Weight (with stand)	4500 g
Depth (without stand)	38 mm
Height (without stand)	356 mm
Weight (without stand)	3700 g
