English
3.1 OSD Setting Menus
Follow the instructions indicated on the bottom of the OSD Function Menu. Press
/ on the control panel or / arrow keys on the remote control to scroll
through the menus. press VOL+ on the control panel or OK on the remote control to
select an item and then press MENU to exit the OSD menu. The following menus
can be set by different adjustment methods.
3.2 Storing Channels into Memory
1 Press MENU to display the OSD main menu.
2 Press / to select the Channel menu, and
then press to enter.
3 Press / to select Air/Cable and use /
to select Air or Cable.
Air: RF signal programs by air.
Cable: RF signal programs by cable.
4 Press / to select Auto Scan, and then
press to enter.
5 Press / to select Scan all channels,
Digital channel only, or Analog channel only,
and press to perform Auto Scan function. To
stop scanning, press MENU at any time.
6 The Auto Scan screen will be shown, and after it
is done, the screen will return to the first found
channel.
CH CH
Cable
19
Channel
Air/Cable
Auto Scan
Favorite
Show/Hide
Channel No.
Channel Label
DTV Signal
OK
EnterMove
Return
Return
Menu
Exit
OK
EnterMove
Return
Return
Menu
Exit
Channel
Scan all channels
Digital channel only
Analog channel only
OK
EnterMove
Return
Return
Menu
Exit
Channel
RF CH : 1
Found : 0
Analog : 0
Digital : 0
RF CH :
Found :
Analog :
Digital :
1
0
0
0
17
English

AOC LE23H062 Specifications

General

Package depth	445 mm
Package width	616 mm
Package height	118 mm
Package weight	6800 g
Child lock	No
Plug and Play	Yes
Image formats supported	JPG
Display diagonal	23 \
Display brightness	300 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	1080p
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Viewing angle, horizontal	170 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Certification	FCC, cULus, RoHS, EPA4.0
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	60 Hz
Power consumption (typical)	45 W
RMS rated power	10 W

Weight and Dimensions

Depth (with stand)	190 mm
Width (with stand)	561 mm
Height (with stand)	389 mm
Weight (with stand)	4500 g
Depth (without stand)	38 mm
Height (without stand)	356 mm
Weight (without stand)	3700 g
