CONCEPT1T Version
17. RS232: 9 pin sub D connector for connection of computers or
other automated audio system controllers
18. AC input: plug in the supplied mains cable here. Check your
mains voltage first !
Difference on CONCEPT1T
1. lo-cut Right channel / zone 2: switch not available
2. Right channel / zone 2 output on euroblock connector:
minimum load impedance: 167 ohms or 60 watts / 100 volts
3. lo-cut Left channel/zone 1: switch not available
4. Left channel / zone 1 output on euroblock connector: minimum
load impedance: 167 ohms or 60 watts / 100 volts
21 3 4
