Instruction manualCONCEPT1(T)
19
Technical Specifications
CONCEPT 1
Dynamics program power, both
channels driven, 8 ohm
50 W + 50 W
Dynamics program power, both
channels driven, 4 ohm
80 W + 80 W
Dynamics capacity at 1,7 ohm
dips / ch
120 W
Note Power output controlled by digital
limiter
Lo-cut filter 75 Hz / 12 dB / oct
Speaker impedance - connection 4 - 16 ohms / ch - euroblock
secured screw terminals
Digital control
RS232 Sub-d9, galvanically isolated
IR (ir-remote control optional) Front ir eye, rear mini-jack
Inputs / outputs
Source inputs a-b-c-d input
impedance / sensitivity
15 kΩ / 0,3 V -10 dBV, max 2,7 V
+8,5 dBV
Source inputs a-b-c-d digital preset
gain range
-20 / +14 dB
Source digital tone control Bass 90 Hz, treble 15 kHz, +/- 14 dB
Automatic loudness +6 dB (90 Hz) / +4 dB (15 kHz) to
flat 0 dB
Micro balanced input impedance /
sensitivity
1,5 kΩ / 1,5 mV -56 dBV,
max 0,4 V -8 dBV
