APART concept1t - Technical Specifications - General; General and Physical Details

20
Integrated amplifiers
Micro balanced input rear panel
gain trim
-56 / -16 dBV mic - line
Micro tone control ; rear panel
lo - hi
100 Hz / +3 dB,10 kHz / -6 dB to
100Hz/-9 dB, 10 kHz / +4 dB
Pre-out impedance / sensitivity 1 K ohm / 0 dBV
Line-out impedance / sensitivity 1 K ohm / +3 dBV
General
Operation modes Stereo / 2 zones linked / 2 individual
zones
Micro paging 1 or 2 zone
Frequency response (- 0,5 dB) 10Hz - 40 kHz
THD < 0,05%
IMD < 0,09%
Noise a-weighted > 100 dBV
Gain 33 dB
Damping factor > 100
Protection systems Dc, temp, clip, overcurrent, short-
circuit
Cooling Convection, no fan
Power consumption Max 170 watts
Mains power requirements 240 - 230 VAC, 50-60 Hz
Temperature operating range 0 - 40 °C
Physical specifications
Net dimensions (w x h x d) mm 430 (Without rackears) x 88 x 290
(320 including knobs)
Gross dimensions (w x h x d) mm 530 X 380 x 170
