9.0 Specifications
9.1 Input UPS version (Vac): 100 120 220/230/240
Nominal input voltage (Vac): single phase 100 120 230
Nominal input frequency: 50 or 60 Hz.
Internally selected by microprocessor.
Input protection: 5 Amp 5 Amp 2.5 Amp
Push-to-reset circuit breaker.
Input connections: IEC 320 male inlet coupler. 120 and 100 Vac versions
include 6 ft (2 m) line cord, with a NEMA 5-15P three pronged plug.
9.2 Transfer characteristics
Frequency limits for on-line operation: 50 or 60 Hz, ±5%
Lower input voltage, on-line operation: 80 Vac 90 Vac 173 Vac
Upper input voltage, on-line operation: 110 Vac 132 Vac 253 Vac
SmartBoost operation line voltage (Vac): 80–90 90–103 173–196
Transfer time: 2 ms typical;
(1 ms is 0.001 seconds). 4 ms maximum.
9.3 Output characteristics
On-battery output voltage (Vac): 100 ±5% 115 ±5% 225 ±5%
Maximum output current: 2.5 Amp 2.2 Amp 1.1 Amp
Maximum load: 250 VA or
175 W at 0.7 power factor
On-battery Frequency: 50 or 60 Hz, ±0.1 Hz.
Synchronized to mains frequency during brownout.
On-battery waveshape: sinewave.
Protection: Overcurrent and short-circuit protected, latching shutdown
upon overload.
Output connections: 100 and 120 Vac versions have two NEMA 5-15R
receptacles. 220/230/240 Vac version has two IEC 320 output couplers and
includes two 6 ft (2 m) output cords with IEC 320 couplers and one IEC
rewireable plug adapter.
