Revision 5 - 50 - November 2017
12. Adjust carrier rail alignment.
1) Loosen lower nut.
2) Turn upper nut to raise or lower rail.
3) Slide rail left or right to align with
tub rails.
4) Tighten lower nut.
Attention: Make sure rails are tight
and chair wheels are aligned with rails.
Verify all fasteners and adjusting nuts
are tight before using transfer system.
13. Return chair to carrier.
14. Release carrier from tub.
To Next Page
