SV200 AC Servo Drive User Manual
920-0096H
2/6/2018
2 Product Description
2.1 Unpacking Check
Please refer to this section to confirm the model of servo drive and servo motor .
A complete and workable AC servo system should include the following parts:
* Matched Servo drive and Servo motor
* A power cable connect the drive to the servo motor
* A feedback encoder cable connecting the drive to the motor
* A mini (Type B) USB cable connect the port CN1 to PC for communication. (Not needed for Ethernet drives)
* 50-PIN connector (For I/O connections, Port CN2)
* 26-PIN connector(For encoder feedback, Port CN3 )
* 10-PIN connector (For STO, Port CN5) (Required)
* RJ-45 CAT5 patch cables (For RS-485, Ethernet or CANopen communication, Port CN6 and CN7)(user
supplied)
* 5-PIN connector (For L1,L2,L3,L1C,L2C)
* 6-PIN connector(For U,V,W,B1+,B2,B3)
2.2 Servo Drive Model Introduction
2.2.1 Drive Name Plate Description
Model No.
Input/Output Voltage
Phase
Rated Current
Frequency
Rated Power
Model No. XXXX-XXXXX
Serial No.
09450001
INPUT
1.8 A
OUTPUT
VOLT.
1 /3φ φ
0-240VAC
3φ
2.6 A/1.5A
200-240VAC
PHASE
F.L.C
FREQ.
POWER
50/60Hz
0-400Hz
200W
AC SERVO
DRIVE
SV200
Assembled in China
RoHS
