General information
chap. 1
1-17
1
Release 00 2002-09
Atlantic 500
DIMENSIONS
Max. length
Max. width
Saddle height
Wheelbase
Minimum ground clearance
Weight in operating condition
89.4 in (2270 mm)
28.3 in (720 mm)
30.7 in (780 mm)
62.0 in (1575 mm)
5.9 in (150 mm)
440.9 lbs (200 Kg)
Max. height (al front fairing) 57.0 in (1450 mm)
ENGINE
Number of cylinders
Total displacement
Engine rpm idling
Clutch
Gearshift
Lubrication
1
28.0 cu.in
(460 cm
3
)
10.5 : 1
1450 ± 50 rpm
Automatic, dry centrifugal
Automatic
Forced circulation with trochoidal pump (in the crankcase), oil
filter and pressure regulator by-pass
Type
Single- cylinder 4- stroke, 4 valves, single shaft with camshaft
at the head, controlled by chain on the flywheel side
Cooling Fluid with forced circulation by centrifugal pump
Number of valves
4
Bore / stroke
3.6 in / 2.7 in (92 mm / 69 mm)
Starting
Electric
CAPACITY
Fuel (including reserve)
Seats
Vehicle max. load
(rider + luggage)
1.05 gal (4 l )
2
231.4 lbs (105 Kg)
Fuel reserve
Engine oil
4.48 gal (17 l )
Front fork oil 13.42 cu.in (220 cm
3
) (for tube)
- engine oil and oil filter change
91.5 cu.in (1500 cm
3
)
- change due to engine overhaul
103.7 cu.in
(1700 cm
3
)
Trasmission oil ~ 15.25 cu.in
(250 cm
3
)
Coolant
(50% water + 50% antifreeze with ethylene glycol)
0.39 gal (1.5 l )
TECHNICAL SPECIFICATIONS
Compression ratio
Variator
Primary
Secondary
Total engine / wheel ratio
Trapezoidal belt
Gears
DRIVE
Continuous automatic
short 1/11.988
long 1/4.86
Vehicle max. load
(rider + passenger + luggage)
396.8 lbs (180 Kg)
Model
Choke
Diameter 1.53 in (39 mm)
THROTTLE BODY
Ø 1.5 in (38 mm) and single injector
CONTINUED
To Next Page
