APRILIA ATLANTIC 500 Workshop Manual

Electrical system
chap. 6
6-9
6
Release 00 2002-09
Atlantic 500
CONNECTIONS TO THE E.C.U. CONTROL UNIT
COMPONENT
RPM Sensor 7 - 12 680 Ω B - B/N
Stepper Motor 14 - 24 52 Ω Az - Ro
Stepper Motor 6 - 21 52 Ω Vi - G
Accelerator Sensor 1 - 22 5 kΩ M/Bi - Gr
Accelerator Sensor 1 - 11 1 - 6 kΩ M/Bi - M/G
Fuel Inj. Air Terminal 18 - 22 see tab. Ro/N - Gr
Fuel Inj. H
2
O Terminal 4 - 22 see tab. Ar - Gr
Drop Sensor 16 -22 62 kΩ * Ro/G - Gr
Coil 20 0.6 Ω Ar/Bi - R/M
Fuel Injector 13 14.5 Ω Gr/R - R/M
TERMINAL
RATED
VALUE
CABLE
COLOURS
* With drop sensor in the upright position.

APRILIA ATLANTIC 500 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Front Tire	120/70 - 14
Rear Tire	140/60 - 14
Front Brake	Single disc
Rear Brake	Single disc
Seat Height	780 mm
Fuel Capacity	15 liters
Rear Suspension	Double hydraulic shock absorber with adjustable preload
