Aprimatic GA-MATIC BASIC CF800 - 13 Technical Specifications

DS41242-001 27
13 TECHNICAL SPECIFICATIONS
Model CF 800 CF 1000
Power Input 200-240VAC - 50/60Hz 200-240VAC - 50/60Hz
Output power 235W 245W
Max force 800N 1000N
Open/Close speed 0.15m/s 0.15m/s
Lamp LED 24VDC LED 24VDC or bulb 220VAC
Light time 3 minutes 3 minutes
Decoding Rolling code Rolling code
Batteries (optional) 2 batteries 12 V 3,5 A 2 batteries 12 V 3,5 A
Radio frequency 433.92MHz or other on request 433.92MHz or other on request
Working temperature
-
20° ÷ 40°
-
20° ÷ 40°
Relative humidity < 90% < 90%
Max door area 12 m
2
14 m
2
Engine 24VDC 24VDC
Programmable Remote control Up to 20 Up to 20
Dimensions 400 x 250 x 150mm 400 x 250 x 150mm
DIMENSIONS mm
Width
Height
Depth
Max stroke
