CHAPTER 3
UNIT DESCRIPTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-1000 Series 3 - 7 OM-001-01000-000-04.0
Power / PF Selection
POWER / PF display Displays the:
• Power (in kW)
• Power Factor
P indicator When ON, displays output Power (kW).
PF indicator When ON, displays Power Factor.
M1 indicator When On, indicates Program Memory 1 is selected.
M2 indicator When On, indicates Program Memory 2 is selected.
M3 indicator When On, indicates Program Memory 3 is selected.
M1 button Selects Program Memory 1, as the active instruction set.
M2 button Selects Program Memory 2, as the active instruction set.
M3 button Selects Program Memory 3, as the active instruction set.
APS-1000 Power / PF Display
P O W E R / PF
M1 M2 M3
P
PF
