aptos MAC 800R - Features and Compliance; Grid Support Details

24
8.4 Mechanical Data
8.5 Features
*Note: Voltage and frequency ranges can be extended beyond nominal if required by the utility.
9. Grid Support Details
The MAC
TM
800R Microinverter is a grid support interactive inverter, which is also known as a
Grid Support Utility Interactive Inverter. These microinverters comply with California Rule 21.
The Grid Support Support functions are controlled on Aptos Monitoring Platform and the DTU is
required in this PV system.
Only an authorized installer is allowed to make Grid profile adjustments by following the
requirements of local electrical utility.
Simultaneous use of Fixed Power Factor and Volt/Var is not supported.
 Manufacturer’s Stated Accuracy
Night time power consumption (mW)
<50
Model
Ambient temperature range (℃)
-40 ~ +65
Storage temperature range (℃)
-40 ~ +85
Dimensions (W×H×D mm)
250×170×28
Weight (kg)
Enclosure rating
Outdoor-NEMA (IP67)
Cooling
Natural convection – No fans
Model
Communication
2.4GHz Proprietary RF(Nordic)
Monitoring
Aptos Monitoring System
(Aptos DTU is required)
Compliance
UL1741, IEEE1547, UL1741 SA (240Vac), CA
Rule21 (240Vac), CSA C22.2 No. 107.1-16, FCC
15B, FCC 15C
PV Rapid Shutdown
Confirms with NEC-2014 and NEC-2017 Article
690.12 and CEC-2018 Sec 64-218 Rapid Shutdown
of PV Systems
Measurement
Default Tolerance of Measurement
