aptos MAC 800R - Key Specifications and Dimensions

8
Aptos Solar Technology's 2-in-1 unit microinverter MAC
TM
800R is the perfect solution for PV
systems with an uneven number of panels due to its industry-leading 96.50% (peak efficiency
96.70%).
3.2 Highlights
- Peak output power up to 600W/700W/800W; Adapted to 60 & 72 cells PV panels.
- Peak efficiency 96.70%; CEC weighted efficiency 96.50%.
- Static MPPT efficiency 99.80%; Dynamic MPPT efficiency 99.76% in overcast weather.
- Power factor (adjustable) 0.8 leading……0.8 lagging.
- External antenna for stronger communication with DTU.
- High reliability: NEMA6 (IP67) enclosure; 6000V surge protection.
3.3 Terminals Introduction
3.4 Dimension(mm)
Object
Description
A
AC Connector (Male)
B
AC Connector (Female)
C
DC Connectors
