aptos MAC 800R - Wiring Diagram - 120 Vac; 208 Vac Three Phase

29
WIRING DIAGRAM – 120VAC / 208VAC THREE PHASE:
GROUND
NEUTRAL
W
AC DISTRIBUTION PANEL
OR SUBPANEL
METER
AC BRANCH CABLE
BROWN - L
BLUE - N
YELLOW&GREEN - G
BRANCH END CAP
L1
L2 L3
PHASE-L1&L2
PHASE-L1&L3
PHASE-L2&L3
ETHERNET CONNECTION
TO BROADBAND ROUTER
CONNECTION TO DTU
POWER ADAPATER
5V
© 2021 Aptos Solar Technology, LLC. All rights reserved.
UP TO 5 MAC
TM
800R
PER AC BRANCH CIRCUIT
UP TO 5 MAC
TM
800R
PER AC BRANCH CIRCUIT
UP TO 5 MAC
TM
800R
PER AC BRANCH CIRCUIT
DTU
UP TO 49 MAC
TM
800R
