aptos MAC 800R - Power Factor and Volt;VAr Control; Frequency-Watt and Volt-Watt Control; Ramp Rate and Soft Start

26
 SA11: Ramp Rate (RR) and Soft Start (SS)
 SA12: Specified Power Factor (SPF)
 SA13: Volt/VAr (VV)
 SA14: Frequency-Watt (FW)
 SA15: Volt-Watt (VW)
Units
Adjustment Range
Tolerance
Max
Min
Ramp up
rate
%Irated/s
100
1
+/- 4%
Soft ramp up
rate
%Irated/s
100
0.1
+/- 4%
Adjustment Range
Max
Min
Inductive, under excited, power factor
-0.8
-1.0
Capacitive, overexcited, power factor
1.0
0.8
Units
Output power rating
W
Reactive power absorption (inductive, under
excited)
VAr
Reactive power production (capacitive,
overexcited)
VAr
Units
MAC
TM
800R
Output power rating
W
766
Manufacturer's stated P(f) accuracy
%Prated
5%
Maximum slope of frequency droop
%Prated/Hz
100
Minimum slope of frequency droop
%Prated/Hz
20
Units
Output power rating
W
Output Power accuracy
%Prated
Maximum Slope of active power reduction
%Prated/Hz
Minimum Slope of active power reduction
%Prated/Hz
© 2021 Aptos Solar Technology, LLC. All rights reserved.
MAC
TM
800R
245
245
766
MAC
TM
800R
766
5%
50
20
